1500W Industrial CNC Plasma Cutter High Precision Aluminium Cutting
Machine
Description:
1. Cutting can continue when power fails.
Positioning and cutting can be done randomly.
2. More solid and stable gantry and rails.
3. Economic design:plasma and flame head on one machine.
4. Advanced material inclined discharging design.
5. High cutting speed, high cutting precision and lower maintenance
cost.
6. Plasma torch power supply and supporting all famous brands, a
number of national patents by the manufacturers.
7. Continuous return can be done.
8. It solve the traditional manual processing method thoroughly.The
efficiency of working increased by several times.
Application:
The cutting accuracy reaches the excellent target for the cutting
of Aluminum Sheet, Stainless Steel Plate, Titanium Plate, Copper
Plate, Galvanized Sheet, Advertising with Luminous
Three-Dimensional Characters and Metal Panel with T-shot. The
cutting incision is small, tidy and neat, with no burr, so that
avoid the second process.
Technical Parameters for Light Gantry CNC Cutting Machine:
| 1 | Cutting shape | Steel plate with any plane shapes fromed by straight lines and arcs |
| 2 | LCD Display Dimension | 7.0 Inches |
| 3 | Effective Cutting Size | 2500*6000mm |
| 4 | Railway Size | 3000*7000mm |
| 5 | Plasma Cutting Thickness | 0.5--20mm ( Depends on plasma power source capacity) |
| 6 | Flame Cutting Thickness | 5--200mm |
| 7 | Lifting body | 1 lifting body standard |
| 8 | Cutting Speed | 0-8000mm per minute |
| 9 | Height Control | Electric Height Control+Arc Voltage Height Control(THC) |
| 10 | Drive Mode | Bilateral drive |
| 11 | Cutting Mode | flame and plasma |
| 12 | Ignition device | Auto ignition device |
| 13 | File transmission | USB transmission |
| 14 | Gas Pressure | Max. 0.1Mpa |
| 15 | Oxygen Pressure | Max.0.7Mpa |
| 16 | Cutting Gas | Flame: Oxygen+ Acetylene/ Propane/ Coal gas Plasma :air |
| 17 | Software | FastCAM Standard (support Auto CAD/ Solidworks/ CAXA/ Types etc.) |
| 18 | Cutting accuracy | ±0.5mm |
| 19 | Power Supply Voltage/Frequency | 220V 50HZ / 60HZ |
| 20 | Rated Power Supply | 1500W |
| 21 | Working Temperature | -10℃-60℃, Relative Humidity, 0-95%. |
